Donut-shaped domain supported at the interior circle and loaded tangentially at 5 points along the exterior boundary.
"GRAND — Ground structure based topology optimization for arbitrary 2D domains using MATLAB." T. Zegard and G. H. Paulino. Journal of Structural and Multidisciplinary Optimization 50(5), 2014.
